<9. Configuration>
9-12
IM 21B04C01-01E
Table 9.15 View Object for Resource Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3
VIEW
4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 RS_STATE 1 1
8 TEST_RW
9 DD_RESOURCE
10 MANUFAC_ID 4
11 DEV_TYPE 2
12 DEV_REV 1
13 DD_REV 1
14 GRANT_DENY 2
15 HARD_TYPES 2
16 RESTART
17 FEATURES 2
18 FEATURE_SEL 2
19 CYCLE_TYPE 2
20 CYCLE_SEL 2
21 MIN_CYCLE_T 4
22 MEMORY_SIZE 2
23 NV_CYCLE_T 4
24 FREE_SPACE 4
25 FREE_TIME 4 4
26 SHED_RCAS 4
27 SHED_ROUT 4
28 FAULT_STATE 1 1
29 SET_FSTATE
30 CLR_FSTATE
31 MAX_NOTIFY 1
32 LIM_NOTIFY 1
33 CONFIRM_TIME 4
34 WRITE_LOCK 1
35 UPDATE_EVT
36 BLOCK_ALM
37 ALARM_SUM 8 8
38 ACK_OPTION 2
39 WRITE_PRI 1
40 WRITE_ALM
41 ITK_VER 2
42 SOFT_REV
43 SOFT_DESC
44 SIM_ENABLE_MSG
45 DEVICE_STATUS_1 4 2
46 DEVICE_STATUS_2 4
47 DEVICE_STATUS_3 4 2
48 DEVICE_STATUS_4 4 1
49 DEVICE_STATUS_5 4
50 DEVICE_STATUS_6 4
51 DEVICE_STATUS_7 4
52 DEVICE_STATUS_8 4
Total (in bytes) 22 30 54 31
Table 9.16 Indexes of View for Each Block
VIEW_1 VIEW_2 VIEW_3 VIEW_4
Resourse Block 40100 40101 40102 40103
Transducer Block
40200 40201 40202,
40203
40204
through
40211
AO Function Block 40500 40501 40502 40503
DI1 Function Block 40600 40601 40602 40603
DI2 Function Block 40610 40611 40612 40613
PID or PID1 (with
/EE) Function Block 40800 40801 40802 40803
PID2 Function
Block
40810 40811 40812 40813
OS Function Block 41400 41401 41402 41403
IS Function Block
41700 41701 41702 41703
AR Function Block 41750 41751 41752 41753
9.6.4 Function Block Parameters
Function block parameters can be read from the
host or can be set. For a list and details of the
parameters of blocks held by the YVP110, refer to
the chapter for each function block and the list of
parameters in the latter part of this manual.
