A1.9 IO_OPTS - Availability of Options for Each Block
Bit Contents DI AO
0 Invert ×
1 SP-PV Track in Man ×
2 Reserved
3 SP-PV Track in LO ×
4 SP Track retained target ×
5 Increase to close ×
6 Fault State to value ×
7 Use Fault State value on restart ×
8 Target to Man if Fault State activated ×
9 Use PV for BKCAL_OUT ×
10 Low cutoff
11 Reserved (SIS-Latch Fstate)
12 Units Conversion
A1.10 STATUS_OPTS - Availability of Options for Each Block
Bit Contents DI AO OS PID IS
0 IFS if BAD IN ×
1 IFS if BAD CAS_IN Ч Ч
2 Use Uncertain as Good Ч Ч
3 Propagate Fault Forward ×
4 Propagate Fault Backward Ч Ч
5 Target to Manual if BAD IN ×
6 Uncertain if Limited
7 BAD if Limited
8 Uncertain if Man mode Ч Ч
9 Target to next permitted mode if Bad CAS_IN ×
A1.11 CONTROL_OPTS - Availability of Options for Each Block
Bit Contents PID
0 Bypass Enable ×
1 SP-PV Track in Man ×
2 SP-PV Track in ROut ×
3 SP-PV Track in LO or IMan ×
4 SP Track retained target ×
5 Direct Acting ×
6 Reserved
7 Track Enable ×
8 Track in Manual ×
9 Use PV for BKCAL_OUT ×
10 Act on IR
11 Use BKCAL_OUT with IN_1
12 Obey SP limits if Cas or RCas ×
13 No OUT limits in Manual ×
14 Reserved
15 Reserved
