Table 9.8
View Object for Transducer Block
Relative
index
Parameters
VIEW
1
VIEW
2
VIEW
3 1st
VIEW
3 2nd
VIEW
4 1st
VIEW
4 2nd
VIEW
4 3rd
VIEW
4 4th
VIEW
4 5th
VIEW
4 6th
VIEW
4 7th
VIEW
4 8th
1
ST_REV
2
2
2
2
2
2
2
2
2
2
2
2
2
TAG_DESC
3
STRATEGY
2
4
ALERT_KEY
1
5
MODE_BLK
4
4
6
BLOCK_ERR
2
2
7
UPDATE_EVT
8
BLOCK_ALM
9
TRANSDUCER_
DIRECTORY
10
TRANSDUCER_TYPE
2
2
2
2
11
XD_ERROR
1
1
12
CORRECTION_DIRCTORY
13
FINAL_VALUE
5
5
14
FINAL_VALUE_RANGE
11
15
FINAL_VALUE_CUTOFF_
HI
4
16
FINAL_VALUE_CUTOFF_
LO
4
17
FINAL_POSITION_VALUE
5
5
18
SERVO_GAIN
4
19
SERVO_RESET
4
20
SERVO_RATE
4
21
ACT_FAIL_ACTION
1
22
ACT_MAN_ID
4
23
ACT_MODEL_NUM
32
24
ACT_SN
32
25
VALVE_MAN_ID
4
26
VALVE_MODEL_NUM
32
27
VALVE_SN
32
28
VALVE_TYPE
1
29
XD_CAL_LOC
32
30
XD_CAL_DATE
7
31
XD_CAL_WHO
32
32
ALARM_SUM
8
8
33
POSITION_CHAR_TYPE
1
34
POSITION_CHAR
35
LIMSW_HI_LIM
4
36
LIMSW_LO_LIM
4
37
ELECT_TEMP
4
4
38
TEMPERATURE_UNIT
2
39
SUPPLY_PRESSURE
4
40
SPRING_RANGE
11
41
OUT_PRESSURE
4
4
42
SERVO_OUTPUT_SIGNAL
4
4
43
SERVO_RATE_GAIN
4
44
SERVO_DEADBAND
4
45
SERVO_OFFSET
4
46
BOOST_ON_THRESHOLD
8
47
BOOST_OFF_
THRESHOLD
8
48
BOOST_VALUE
8
49
SERVO_I_SLEEP_LMT
4
50
SERVO_P_ALPHA
4
