A-22
IM 21B04C01-01E
Index
(SM)
Parameter Name Sub-parameter Name (Sub Index)
Default Factory
Setting
Access Remarks
370 PLME_BASIC_
CHARACTERISTICS
0 R
1 ChannelStatisticsSupported 0x00
2 MediumAndDataRatesSupported 0x4900000000000000
3 IecVersion 1 (0x1)
4 NumOfChannels 1 (0x1)
5 PowerMode 0 (0x0)
371 CHANNEL_STATES 0 R
1 channel-1 0 (0x0)
2 channel-2 128 (0x80)
3 channel-3 128 (0x80)
4 channel-4 128 (0x80)
5 channel-5 128 (0x80)
6 channel-6 128 (0x80)
7 channel-7 128 (0x80)
8 channel-8 128 (0x80)
372 PLME_BASIC_INFO 0 R
1 InterfaceMode 0 (0x0)
2 LoopBackMode 0 (0x0)
3 XmitEnabled 1 (0x1)
4 RcvEnabled 1 (0x1)
5 PreferredReceiveChannel 1 (0x1)
6 MediaTypeSelected 73 (0x49)
7 ReceiveSelect 1 (0x1)
373 LINK_SCHEDULE_ACTIVATION_VARIABLE RW
374 LINK_
SCHEDULE_LIST_
CHARACTERISTICS_
RECORD
0 R
1 NumOfSchedules 0
2 NumOfSubSchedulesPerSchedule 1
3 ActiveScheduleVersion 0
4 ActiveSheduleOdIndex 0
5 ActiveScheduleStartingTime 0
375 DLME_SCHEDULE_
DESCRIPTOR.1
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
376 DLME_SCHEDULE_
DESCRIPTOR.2
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
377 DOMAIN.1 Read/write impossible.
Get-OD possible.
378 DOMAIN.2 Read/write impossible.
Get-OD possible.
A2.5.2 Descriptions for LM Parameters
The following describes LM parameters of a YVP.
IMPORTANT
Do not turn off the power to the YVP immediately
after setting. When the parameters are saved
to the EEPROM, the redundant processing is
executed for the improvement of reliability. If
the power is turned off within 60 seconds after
setting is made, the modified parameters are not
saved and the settings may return to the original
value.
(1) DlmeLinkMasterCapabilitiesVariable
Bit
Position Meaning
Description Value
B3: 0x04 LAS
Schedule in
Non-volatile
Memory
Whether the LAS schedule can
(=1) or cannot (=0) be saved to
the non-volatile memory
1
B2: 0x02 Last Values
Record
Supported
Whether to support (=1) or not to
support (=0) LastValuesRecord.
0
B1: 0x01 Link Master
Statistics
Record
Supported
Whether to support (=1)
or not to support (=0)
DlmeLinkMasterStatisticsRecord.
0
