<7. Standard Specifications>

7-4

IM 21B04C01-01E



Optional Specifications (For Explosion Protected types)

Item

Description

Code

Explosionproof type

CSA Explosionproof Approval*

Applicable standard: C22.2 No. 0, No. 0.4, No. 0.5, No. 25, No. 30, No. 94, No. 1010.1

Certificate: 1186507

Explosionproof for Class I, Division 1, Class B, C & D; Class II, Groups E, F & G.,

Class III.

Enclosure Type: NEMA4X Temp. Class: T5/T6

Amb.Temp.: –40 to 82°C(–40 to 180°F) for T5, –40 to 75°C(–40 to 167°F) for T6

CF1

FM Explosionproof Approval*

Applicable standard: FM3600, FM3615, FM3810, ANSI/NEMA250

Explosion proof for Class 1, Division 1, Groups A, B, C and D;

Dust-ignitionproof for Class II/III, Division 1, Groups E, F and G

Enclosure Type: NEMA 4X Temp. Class: T6

Amb. Temp.: –40 to 80°C (–40 to 176°F )

FF1

FM Intrinsically Safe, Nonincendive Approval*

Applicable standard: FM3600, FM3610, FM3611, FM3810, ANSI/NEMA250

IS/ I, II, III/1/ABCDEFG/T4 Ta=60°C; Type 4X

I/0/AEx ia/IIC/T4 Ta=60°C; Type 4X, NI/I/2/ABCD/T4 Ta=60°C; Type 4X, I/2/IIC/T4

Ta=60°C; Type 4X, S/II/2/FG/T4

Ta=60°C; Type 4X, S/III/2/T4 Ta=60°C; Type 4X

Entity Parameters:

Groups A, B, C, D, E, F, and G and Group IIC Vmax=24 V, Imax=250 mA,

Pi=1.2 W, Ci=1.76 nF, Li=0 mH

FISCO Parameters:

Groups A, B, C, D, E, F, and G and Group IIC Vmax=17.5 V, Imax=360 mA,

Pi=2.52 W, Ci=1.76 nF, Li=0 mH

Groups C, D, E, F, and G and Group IIB Vmax=17.5 V, Imax=380 mA,

Pi=5.32 W, Ci=1.76 nF, Li=0 mH

Nonincendive Field Wiring Parameters:

Groups A, B, C, D, E, F, and G and Group IIC: Vmax=32 V, Ci=1.76 nF, Li=0 mH

FS15

FM Nonincendive Approval for /EE Software download *

Applicable standard: FM3600, FM3611, FM3810

Class I, Division 2, Group A, B, C, & D

Class II, Division 2, Group F & G and Class III, Division 1

Class I, Zone 2, Group IIC in Hazardous (Classified) locations

Enclosure: “NEMA4X”, Temp. CI.: T4, Amb. Temp. –40 to 60°C (–40 to 140°F)

Vmax.=32V, Ci=3.52 nF, Li=0μH

FN15

ATEX Flameproof Approval*

Applicable standard: EN60079-0:2009, EN60079-1:2007

Certificate: KEMA 10ATEX0023 X

II 2G Ex d IIC T6 or T5 Gb Amb. Temp.: –40 to 65°C (–40 to 149°F) for T6,

–40 to 80°C (–40 to 176°F) for T5

Special fastener: Class A2-50 or more

KF2

ATEX Intrinsically Safe Approval*

Applicable standard: EN60079-0:2006, EN60079-11:2007, EN60079-26:2007,

EN60079-27:2006, EN61241-0:2006, EN61241-1:2004, EN61241-11:2006 and

EN60529

Certificate: KEMA 08ATEX0114 X

II 1G Ex ia IIB/IIC T4

II 1D Ex iaD 20 IP65 T100°C

II 1D Ex tD A20 IP65 T100°C

Maximum Surface Temperature for dust proof: T100°C

Ambient Temperature for Ex ia/Ex iaD: –40 to 60°C (–40 to 140°F)

Ambient Temperature for Ex tD: –40 to 80°C (–40 to 176°F)

Enclosure: IP65

For Ex ia IIC or Ex iaD: Ui=24.0 V, Ii=250 mA, Pi=1.2 W, Ci=1.76 nF, Li=0 μH

For Ex ia IIB/ IIC or Ex iaD (FISCO model): Ui=17.5 V, Ii=380 mA, Pi=5.32 W, Ci=1.76 nF,

Li=0 μH

For II 1D Ex tD: Input signal: 32 Vdc, Output current: 17 mA

KS25

ATEX Intrinsically safe (Ex ic) / Type n (Ex nA)

*2 *5

Applicable standard: EN60079-0:2009/EN60079-0:2012(Ex ic/Ex nA),

EN60079-11:2012(Ex ic), EN60079-15:2010(Ex nA)

Amb. Temp: –30 to 75°C (–22 to 167°F), Enclosure: IP65

Ex ic: II 3G Ex ic IIC T4 Gc (Intrinsically safe) Ui=32 V, Ci=3.52 nF, Li=0 μH

Ex nA: II 3G Ex nA IIC T4 Gc (Non-sparking) 32 V DC MAX.

KN25

TIIS Flameproof Approval*

Certificate: TC15453, TC15452 for option code /BP

Ex d IIC T6 Amb. Temp.: –20 to 60°C

JF3

Attached flameproof

packing adapter*

Electrical connection: G1/2 female

Applicable cable: O.D. 8 to 12 mm

G11
