Avaya Cajun P880 - Manual (Page 136)

1-126
Chapter 1
Avaya P550R/P580/P880/P882 Multiservice Switch ATM Uplink CLI Reference Guide, Version 2.0
vport
Command Mode
Configuration
Description
Create or delete an ATM Port (VPORT). Use the no form of this
command to delete a VPORT. Virtual Ports are used to specify Virtual
Path numbers. By Default, a single VPORT is created for Virtual Path
0.
* Note: Before creating a VPORT, you must reduce the Traffic
Shape Rate (CPS) and Max VCI on the other VPORT(s)
to free up bandwidth for the new VPORT.
Syntax
vport
no vport
Table 1-76. Parameters, Keywords, Arguments
Sample Output
This example creates a VPORT on physical port 1 for VP 5.
ATM(configure)# vport 1 5
VPort 1 5 created
Name Definition
interfaceID The ATM interface number. The range of
values is: Minimum = 1, Maximum = 2.
vpiNumber The Virtual Port Interface (VPI) number. The
range of values is: Minimum = 0, Maximum =
255.
