1-92
Chapter 1
Avaya P550R/P580/P880/P882 Multiservice Switch ATM Uplink CLI Reference Guide, Version 2.0
set qos-set (pcr)
Command Mode
Configuration
Description
Set the Peak Cell Rate (PCR) for a QoS set.
Syntax
set qos-set pcr
Table 1-59. Parameters, Keywords, Arguments
Sample Output
This example sets the peak cell rate for QoS set 24 in QoS Domain
12 to a value of 2500 cps.
ATM(configure)# set qos-set 12 24 pcr 2500
PCR set successfully
Name Definition
qosDomainID The QoS domain ID number. The range of
values is: Minimum = 1, Maximum = 128.
qosHandle The QoS set ID number. The range of values is:
Minimum = 0, Maximum = 1000.
Note:
this parameter must be unique across
ALL QoS Sets irrespective of QoS
Domains. In other words, every QoS
Set must have a unique qosHandle
within an ATM Uplink module.
pcr-value The peak cell rate value, measured in cells per
second. The range of values is: Minimum = 0,
Maximum = 1412830(OC12) or 353206(OC3).
