HDXP Plus Series Switchers • Remote Configuration and Control
60
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Lock (Executive) Modes
Lock all front panel functions
1X
Exe1
]
Enable lock mode 1.
Unlock all front panel functions
0X
Exe0
]
Enable lock mode 0.
View lock status
X
X(
]
View lock mode status
X(
.
Resets
Reset global presets
and names
E
ZG
}
Zpg
]
Clear all global presets and
their names.
Reset an individual global
preset
E
X1!
ZG
}
Zpg
X1!
]
Clear global preset
X1!
.
Reset all mutes
E
ZZ
}
Zpz
]
Unmute all outputs.
Reset room map
E
ZR
}
Zpr
]
Clear all room definitions.
Reset individual room
E
X*
ZR
}
Zpr
X*
]
Clear all presets for room
X*
.
Reset all room presets and
names
E
ZP
}
Zpp
]
Clear all room presets and
room names.
Reset individual room preset
and name
E
X1@
*
X*
ZP
}
Zpp
X1@
*
X*
]
Clear room preset
X1@
and
name for room
X*
.
Reset whole switcher
E
ZXXX
}
Zpx
]
Clear all ties and presets.
Reset flash memory
E
ZFFF
}
Zpf
]
Reset flash memory (reset
user-supplied files).
Absolute system reset
E
ZQQQ
}
Zpq
]
Clear all ties and presets and
reset the HDXP to factory
defaults. Reset the IP address
to 192.168.254.254
and the subnet mask to
255.255.000.000.
Information Requests
Information request
I
V
X^
x
X&
• A
X^
x
X&
]
V
X^
x
X&
is the number of
video inputs by the number of
video outputs.
A
X^
x
X&
is the number of
audio inputs and outputs.
Because the HDXP does not
have audio, this part of the
response is always A00x00.
Example:
HDXP 3216
I
V32x17 • A00x00
]
The matrix consists of 32
video inputs and 17 video
outputs. (It has no audio
inputs or outputs.)
Request product name
1I
HDXP Plus Series
Request model description
2I
SDI and HD-SDI Matrix Switcher
Request system memory
usage
3I
n bytes used out of
n kBytes
Show amount of memory
used and total memory
available for operations.
Request user memory usage
4I
n bytes used out of
n kBytes
Show amount of user memory
used and total available.
NOTE:
X^
= Total inputs in matrix
Number of inputs on this switcher
X&
= Total outputs in matrix
Number of outputs on this switcher
X*
= Room number (for room presets)
1 – 10. Each room can have up to 10 room presets (
X1@
) assigned.
X(
= Lock mode status
0 = lock mode disabled (front panel is unlocked),
1 = lock mode enabled (front panel is locked)
X1!
= Global preset number
00 – 32. 00 = current configuration
X1@
= Room preset number
1 – 10. Each room (
X*
) can have up to 10 presets assigned.
