HDXP Plus Series Switchers • Remote Configuration and Control 48
] Login Administrator ]
] Login User ]
The switcher initiates the login message when a correct administrator or user password
has been entered. If the user and administrator passwords are the same, the switcher
defaults to administrator privileges.
Qik ]
The switcher initiates the Qik message when a front panel switching or preset recall
operation has occurred.
Sprnn ]
The switcher initiates the Spr message when a memory preset has been saved from the
front panel.
nn is the preset number.
Vmtnn *x ]
The switcher initiates the Vmt message when a video output mute is toggled on or off
from the front panel.
nn is the output number, • is a space, and x is the mute status:
1 = on, 0 = off.
Exen ]
The switcher initiates the Exe message when executive mode is toggled on or off from the
front panel.
n is the executive mode status: 1 = on, 0 = off.
Switcher Error Responses
When the HDXP receives an SIS command and determines that it is valid, it performs the
command and sends a response to the host device. If the switcher is unable to perform
the command because the command is invalid or contains invalid parameters, the
switcher returns an error response to the host. The error response codes are:
E01 — Invalid input channel number (too large)
E10 — Invalid command
E11 — Invalid preset number (too large)
E12 — Invalid output number or port number
E13 — Invalid value (out of range)
E14 — Command not available for this configuration
E17 — Timeout (caused only by direct write of global presets)
E21 — Invalid room number
E22 — Busy
E24 — Privilege violation (Ethernet and Extron software only)
E25 — Device not present
E26 — Maximum number of connections exceeded
E27 — Invalid event number
E28 — Bad file name or file not found
NOTE: User privileges extend to all view and read commands except reading the
administrator password. Users can also create ties, creating and recall presets, and
mute outputs.
