HDXP Plus Series Switchers • Operation 20
Example 2: Adding a tie to a set of ties
In the following example, a new tie is added to the current configuration. The illustrations
show the front panel indications that result from your actions.
NOTE: This example assumes that you have performed example 1.
1. Press and release the Esc > button.
CONTROL
PRESET ENTER ESC VIEW
Press the Esc > to clear all selections.
The button blinks once.
Figure 18. Clearing All Selections
2. If necessary, place the HDXP in matrix switching mode by pressing and releasing the
Matrix button. The button lights steadily green.
I / O
MATRIX PREVIEW
Press the Matrix button to enter matrix mode.
The button lights
green when selected.
Figure 19. Selecting Matrix Mode
3. Press and release the Input 5 button.
1 2 3 4 5 6 7 8
17 18 19 20 21 22 23 24
1 2 3 4 5 6 7 8
INPUTS
OUTPUT
Press and release the Input 5 button.
The button lights
green.
The Output 3, Output 4, and Output 8 buttons
light
green to indicate the ties created in example 1.
Figure 20. Selecting an Input with Ties
4. Press and release the output 1 button.
CONTROL
PRESET ENTER
= Blinking button
ESC VIEW
1 2 3 4 5 6 7 8
OUTPUT
Press and release the Output 1 button.
The button blinks green to indicate that the
selected input will be tied to this output.
The Enter button blinks
green to indicate the need to
confirm the change.
Figure 21. Selecting an Additional Output
