HDXP Plus Series Switchers • Remote Configuration and Control
58
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Output Reclocking
Set the output reclocker
X#
*
X%
=
Rte
X#
*
X%
]
Set the reclocking rate for
output
X#
to
X%
.
View the reclocker status
X#
=
X%
]
Show current reclocking rate
X%
for output
X#
.
Rte
X#
*
X%
]
Verbose mode 2 or 3
Example:
8 * 07 =
Rte 08 * 07
]
The reclocking rate for output
8 is 1485.
I/O Grouping
NOTE: All input and output positions must contain a group number or
0. For example, for the HDXP 3216 or 3232, you
must enter 32 group numbers between
E
and I or between
E
and O. If you do not want to group a particular input
or output, enter 0 in its position.
Write input grouping
E
X1)
X1)
...
X1)
n
I
}
Gri
X1)
X1)
...
X1)
n
]
Each
X1)
entry is the group
number assigned to an input
position, starting from input 1.
n = the maximum number of
inputs for this model.
Example: HDXP 3232 or
HDXP 3216
E
401...3I
}
See below.
Input 1 – group 4
input 2 – group 0 (ungrouped)
...
input 32 – group 3
01
Input:
GrI
Response #s = group:
Input 1 in group 4
02 03 04 05 06 07 08 09 10 11 12
4 0 1 3 3 0 0 0 0 4 4 4 4 1 1 2 2 1 2 2 3 3 3 3
13 14 15 16 17 18 19 20 21 22 23 24
Input 2 not grouped
2 1 2 2 3 3 3 3
25 26 27 28 29 30 31 32
Input 32 in group 3
Write output grouping
E
X1)
X1)
...
X1)
n
O
}
Gro
X1)
X1)
...
X1)
n
]
Each
X1)
entry is the group
number assigned to an output
position, starting from output 1.
n = the maximum number of
outputs for this model.
Read input grouping
E
I
}
X1)
X1)
...
X1)
n
]
Each
X1)
entry is the group
number assigned to an input
position, starting from input 1.
n = the maximum number of
inputs for this model.
Example: HDXP 1616
E
I
}
01
Input:
Response = group:
Input 1 in group 1
02 03 04 05 06 07 08 09 10 11 12
1 1 1 3 3 0 0 0 0 4 4 4 4 1 1 2
13 14 15 16
Input 9 not grouped
Input 16 in group 2
Read output grouping
E
O
}
X1)
X1)
...
X1)
n
]
Each
X1)
entry is the group
number assigned to an output
position, starting at output 1.
n = the maximum number of
outputs for this model.
NOTE:
X#
= Output number
1 – maximum number of outputs for your model
X%
= Output reclocking rate
00 = auto (default), 01 = bypass, 02 = 143 (component NTSC)
03 = 177 (component PAL), 04 = 270, 05 = 360, 06 = 540,
07 = 1485, 08 = 2970
X1)
= Group number for I/O grouping
0 – 4. 0 = not grouped.
