HDXP Plus Series Switchers • Remote Configuration and Control
55
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Mute Commands (continued)
Global video mute
1* B
Vmt1
]
Mute all video outputs.
NOTE: To mute outputs, you can also use the Input
0 command: 0 *
X@
!, where input
X@
is set to 0.
Global video unmute
0 * B
Vmt0
]
Unmute video for all outputs.
View all mutes
E
VM
}
X1$
X1$
...
X1$
n
]
Each
X1$
response is the
mute status of an output,
starting from output 1.
n = the maximum number of
outputs for this model.
Mut
X1$
X1$
...
X1$
n
]
Verbose mode 2 or 3
Example: HDXP 1616
E
VM
}
Mut0100010000000100
]
Outputs 2, 6, and 14 are
muted. All other outputs are
unmuted.
NOTE: The
Mut portion of the response appears only when the switcher is in verbose mode 2 or 3 (see
Save, Recall, and Directly Write Global and Room Presets
NOTES:
•
If you try to recall a global preset that is not saved, the matrix switcher responds with an E11 error code .
•
If you try to save a room preset to a room that has not been defined, the HDXP responds with an E21 code.
•
The following characters are invalid or not recommended in preset names:
+ ~ ,
`
@ = [ ] { } ‘ ’ “ ” ; : | \ and ?
Save the current ties as a
global preset
X1!,
Spr
X1!
]
Save the current configuration
as preset
X1!
. The command
character is a comma.
Example:
9
,
Spr 09
]
Save current ties as preset 9.
Recall a global preset
X1!.
Rpr
X1!
]
Recall global preset
X1!
as
the current configuration.
The command character is a
period.
Example:
5
.
Rpr05
]
Recall preset 5.
Clear a global preset
E
+
X1!
PO*!
}
Spr
X1!
]
Clear all ties in preset
X1!
.
Example:
E
+ 27P0*!
}
Spr27
]
Clear all ties in preset 27.
Save the current ties as a
room preset
X*
*
X1@,
Rmm
X*
• Spr
X1@
]
Save the current configuration
as preset
X1@
for room
X*
.
The command character is a
comma.
Example:
3 * 9
,
Rmm03 • Spr09
]
Save current ties as preset 9
for room 3.
Recall a room preset
X*
*
X1@.
Rmm
X*
• Rpr
X1@
]
Recall preset
X1@
to room
X*
. Command character is a
period.
NOTE:
X*
= Room number (for room presets)
1 – 10. Each room can have up to 10 room presets (
X1@
) assigned.
X1@
= Room preset number
1 – 10. Each room (
X*
can have up to 10 presets assigned.
X1!
= Global preset number
00 – 32. 00 = current configuration
X1$
= Video mute status
For each output: 0 = no mutes, 1 = video mute
