Issue 5.6.A IPDirector V.5.6 – User Manual – Part 7: Editing - IPEdit
EVS Broadcast Equipment - 2009
60
F
IELDS IN THE
C
REATE
T
IMELINE
W
INDOW
Left Pane
The left pane contains the following fields:
Field Description Mandatory ?
Name Name of the timeline in maximum 32 characters. Yes.
Description Description of the timeline in maximum 256
characters
No
LSM ID ID identifying the timeline position in the XNet
network.
The timeline can be stored on bank 10 of any
page of an XT[2] server. The timeline ID is made
up as follows:
< t i m e l i n e p o s i t i o n > / < t i m e l i n e
p a g e >
where:
• The timeline position is between 1 and 99.
• The timeline page is between 1 and 10.
If you enter a requested position that is already
used, the application will display an error
message. You’ll have to enter a new position.
If you do not enter an ID in the Create a New
Timeline window, the Timeline ID is automatically
assigned when IPEDIT creates the timeline.
No
TC Track First TC value of the timeline.
If you do not enter a value for the TC Track in the
Create a New Timeline window, the default TC
track assigned is 00:00:00:00. Yes
Send to Destinations where the timeline can be
transferred to, i.e. either the default archive or a
bin.
Select the check boxes corresponding to the
requested destinations.
No
Publish to User groups to which the timeline can be
published, i.e. made available.
Select the user groups to which the timeline
should be published.
No
Keywords Maximum 5 keywords can be added to describe
the timeline.
To add a keyword to the timeline when the Create
Timeline window is opened, click on a keyword in
either the keyword grid or dictionary when the
Apply button is active in the relevant keyword
No
