Issue 5.6.A IPDirector V.5.6 – User Manual – Part 7: Editing - IPEdit
EVS Broadcast Equipment - 2009
160
To do this, click at the intersection between the source and the output channels
to associate.
• which output channels will be muted.
To do this, click the bullet that corresponds to the output channel. This removes
the bullet, which means that the output channel will be muted.
Summary Information
The information at the right of the output channels summarizes the channel
allocation:
• means that the source channel a7 is assigned to the output channel
a5.
• means that no source channel will be assigned to the output channel
a2. This will be mute.
A
DDITIONAL
O
PTIONS
These options are only available when you access the Swap/Mute Configuration
window from the Swap/Mute Zoom display of a track:
Apply between mark IN and mark OUT
When you have defined a mark IN and mark OUT within which you should apply
the swap or mute function, you need to tick this check box.
Overwrite existing swap/mute
When you have ticked the Apply Between Mark IN and Mark OUT option, you can
tick the Overwrite Existing Swap/Mute option if you want to overwrite possible
swap/mute that might have been previously defined on the selected part of the
track.
Swap Mix Duration
You can add a mix audio effect at the beginning and end of the swap. In this case,
specify the duration of the swap mix in this spin box.
Note
If an audio transition effect is defined where the swap mix is defined, the
transition effect will have priority on the swap mix. The latter will not be
applied.
