background image

IPDirector V.5.6 – User Manual – Part 7: Editing - IPEdit

EVS Broadcast Equipment – May 2009

Issue 5.6.A

37

Modifying the Timeline Name

You can update the timeline name in the Properties window, which is accessible
by right-clicking the Timeline Name field and selecting Properties.

LSM

ID

Description

The LSM ID identifies the timeline position in the XNet network.

The timeline can be stored on bank 10 of any page of an XT[2] server.

The timeline ID is made up as follows:

< t i m e l i n e n u m b e r > / < t i m e l i n e p a g e >

where:

The timeline number is between 1 and 99.

The page is between 1 and 10.

Example

Timeline ID: 33/2. This means the timeline has the position 33 on page 2, bank 10.

4.1.2 T

IMELINE

D

ISPLAY

D

ESCRIPTION

The timeline display is the area where the timeline elements are displayed and

where users edit the timeline.

M

AIN

O

BJECTS IN THE

T

IMELINE

D

ISPLAY

The following screenshot highlights some important objects in the timeline display:
