3.
Install the mounting shelf on the back of the rack rails. Rest the bottom slot of each
flange on a mounting screw.
4.
Partially insert the remaining screws into the open holes in each flange of the mounting
shelf (see
or
).
5.
Tighten all the screws completely.
Figure 34: Installing the Front Mounting Hardware for a Four-Post Rack
or Cabinet
Copyright © 2013, Juniper Networks, Inc.
66
MX480 3D Universal Edge Router Hardware Guide
