WARNING:
Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable
connected to a transceiver emit laser light that can damage your eyes.
4.
Remove the cable connector from the transceiver.
5.
Carefully arrange the disconnected cable in the cable management brackets to prevent
the cable from developing stress points.
CAUTION:
Avoid bending fiber-optic cable beyond its minimum bend
radius. An arc smaller than a few inches in diameter can damage the cable
and cause problems that are difficult to diagnose.
6.
Pull the ejector handle out from the transceiver to unlock the transceiver.
CAUTION:
Make sure that you open the ejector handle completely until
you hear it click. This prevents damage to the transceiver.
Use needlenose pliers to pull the ejector handle out from the transceiver.
7.
Grasp the transceiver ejector handle, and pull the transceiver approximately 0.5 in. (1.3
cm) out of the DPC, MPC, MIC, or PIC.
8.
Using your fingers, grasp the body of the transceiver, and pull it the rest of the way
out of the DPC, MPC, MIC, or PIC.
Figure 117: Removing SFPs or XFPs
9.
Place a rubber safety cap over the transceiver.
10.
Place the removed transceiver on an antistatic mat or in an electrostatic bag.
