Page 48
Related
Documentation
•
•
Replacing an MX480 AS MSC on page 217
MX480 AS MSC LEDs
Two LEDs (
CPU
and
AP
) indicate the status of the AS MSC and are located on the AS
MSC.
describes the functions of the AS MSC LEDs.
Table 4: AS MSC LEDs
Description
State
Color
Label
AS MSC operates normally.
On steadily
Green
CPU
AS MSC has an error or has failed.
On steadily
Red
AS MSC is offline.
Off
–
AS MSC storage operation is normal.
On steadily
Green
AP
AS MSC storage operation has an error.
On steadily
Red
AS MSC storage operation is not activated.
Off
–
Related
Documentation
MX480 Application Services Modular Storage Card Description on page 23
•
•
Replacing an MX480 AS MSC on page 217
MX480 Application Services Modular Processing Card Overview
•
MX480 Application Services Modular Processing Card Description on page 24
•
MX480 Application Services Modular Processing Card Description
The Application Services Modular Processing Card (AS MXC) is a pluggable X86-based
card that can be inserted into the lower slot of the Application Services Modular Line
Card (AS MLC). The AS MXC serves as the processing card for the Junos Content Encore
system and contains the two X86, Intel 8-core processors with interface ability greater
than 80 Gbps. The AS MXC (see
) is equivalent to a PIC or MIC
(Modular Interface Card).
AS MXCs are hot-removable and hot-insertable. One MXC can be installed in the lower
slot of each AS MLC. Each MXC has these components:
•
Two 8-core Intel processors—Contains eight execution cores with Ring Interconnect
architecture. Each core supports two threads, up to 16 threads per socket.
•
64 GB DRAM—On DIMM sockets.
Copyright © 2013, Juniper Networks, Inc.
24
MX480 3D Universal Edge Router Hardware Guide
