DPC Components
Each DPC consists of the following components:
• DPC cover, which functions as a ground plane and a stiffener.
• Fabric interfaces.
• Two Gigabit Ethernet interfaces that allow control information, route information, and
statistics to be sent between the Routing Engine and the CPU on the DPCs.
• Two interfaces from the SCBs that enable the DPCs to be powered on and controlled.
• Physical DPC connectors.
• Two or four Packet Forwarding Engines.
• Midplane connectors and power circuitry.
• Processor subsystem, which includes a 1.2-GHz CPU, system controller, and 1 GB of
SDRAM.
• Online button—Takes the DPC online or offline when pressed.
• LEDs on the DPC faceplate. For more information about LEDs on the DPC faceplate,
see the
MX Series 3D Universal Edge Routers Line Card Guide .
Two LEDs, located on the craft interface above the DPC, display the status of the DPC
and are labeled
OK and FAIL .
Related
Documentation
MX480 Dense Port Concentrator (DPC) LEDs on page 12 •
• DPC and MPC LEDs on the MX480 Craft Interface on page 39
• Replacing an MX480 DPC on page 190
MX480 Dense Port Concentrator (DPC) LEDs
Two LEDs, located on the craft interface above the DPC, display the status of the DPC
and are labeled
OK and FAIL . For more information about the DPC LEDs on the craft
interface, see “DPC and MPC LEDs on the MX480 Craft Interface” on page 39 .
Each DPC also has LEDs located on the faceplate. For more information about LEDs on
the DPC faceplate, see the “LEDs” section for each DPC in the
MX Series 3D Universal Edge
Routers Line Card Guide .
Related
Documentation
MX480 Dense Port Concentrator (DPC) Description on page 10 •
• Maintaining MX480 DPCs on page 130
• Replacing an MX480 DPC on page 190
