Connecting to the CLI at the User End for the SRX210 Services Gateway
To remotely connect to the CLI through a dial-up modem connected to the console port
on the services gateway:
1. Connect a modem at your remote location to a management device such as a PC or
laptop computer.
2. Start your asynchronous terminal emulation application (such as Microsoft Windows
HyperTerminal) on the PC or laptop computer.
3. Select the COM port to which the modem is connected (for example, COM1 ).
4. Configure the port settings shown in Table 32 on page 83 .
Table 32: Port Settings for Connecting to the CLI at User End
Value Port Setting
9600 Bits per second
8 Data bits
None Parity
1 Stop bits
None Flow control
5. In the HyperTerminal window, enter AT .
For more information on the AT commands, see the following topics:
• Initial Configuration for Security Devices
• Monitoring and Troubleshooting for Security Devices
An OK response verifies that the modem can communicate successfully with the COM
port on the PC or laptop.
6. Dial the modem that is connected to the console port on the services gateway by
entering
ATDT remote-modem-number . For example, if the number of the modem
connected to the console port on the services gateway is 0013033033030 , enter ATDT
0013033033030 .
The services gateway login prompt appears.
7. Log in as the user root . No password is required at initial connection, but you must
assign a root password before committing any configuration settings.
Related
Documentation
• Connecting the Modem at the SRX210 Services Gateway End on page 81
• Connecting the Modem to the Console Port on the SRX210 Services Gateway on page 82
• SRX210 Services Gateway Software Configuration Overview on page 85
83 Copyright © 2013, Juniper Networks, Inc.
Chapter 14: Connecting the SRX210 Services Gateway to Management Devices
