• Unlocking ExpressCards — You can unlock GSM ExpressCards from the Junos OS CLI.
If the SIM is locked, you need to unlock it before making a call.
NOTE: Only GSM cards support locking and unlocking of the SIM.
• Interface support — The ExpressCard interface supports the IP over PPP interface from
the network through the wireless link.
• Dial-out support — The dialer interface can place calls and has multiple features such
as dial-backup, dialer-watchlist, and dialer-filter. The dialer interface can use the
ExpressCard to support this feature.
NOTE: The 3G ExpressCard does not support the dial-in feature.
• Card information availability — You can use CLI commands to obtain information on
the ExpressCard, such as type, version, wireless status, and user profiles.
• Security
• GSM cards support PIN lock to prevent unauthorized access and use of the wireless
account.
• You can use the CLI request commands to lock or unlock the SIM card.
• You have the option to store the PIN code you provide in the services gateway
configuration , so that the SIM can be unlocked without user intervention on each
reboot or reset on the box.
NOTE: Currently all GSM cards support PIN-protected SIMs.
Physical Specifications
Table 12 on page 25 lists the physical parameters of the 3G ExpressCard.
Table 12: 3G ExpressCard Physical Specifications
Value Specification
Standard ExpressCard with 34 modules Type
1.33 in. (34 mm) ExpressCard width
0.19 in. (5 mm) Thickness
26 Connector pins
1.3 watts Max power consumption
