Monitoring the SRX210 Services Gateway Power System
The LEDs on the services gateway enable you to determine the performance and
operation. The Power LED, located on the front panel of the services gateway, indicates
the different settings with respect to the power system.
Table 39 on page 108 describes different Power LED status settings and their corrective
actions.
Table 39: Services Gateway Power LED Status
Possible Cause and Corrective
Action
Meaning LED Status
Normal indication. No action is required. The device is receiving
power, and the internal
power supply is functional. Green
Normal indication. No action is required. The Power button has
been pressed and quickly
released. The device is
shutting down or starting
up. Amber
• Verify that the AC power cord from
the power source to the device is not
damaged. If the insulation is cracked
or broken, immediately replace the
cord or cable.
• Ensure that the socket you plug in is
in working condition.
• Ensure the device has an AC input
voltage between 110 and 240 VAC.
• If you cannot determine the cause
of the problem or need additional
assistance, contact the Juniper
Networks Technical Assistance
Center (JTAC). See
“Juniper
Networks Technical Assistance
Center” on page 110
.
The device is not receiving
power. Off
Related
Documentation
Monitoring the SRX210 Services Gateway Chassis Using the CLI on page 101 •
• Monitoring the SRX210 Services Gateway Components Using LEDs on page 103
• Monitoring the SRX210 Services Gateway Using Chassis Alarm Conditions on page 105
• Using the Reset Config Button on the SRX210 Services Gateway on page 109
• Changing the Reset Config Button Behavior on the SRX210 Services Gateway on page 110
• Juniper Networks Technical Assistance Center on page 110
