NOTE: Ensure that the fan (back panel) of your device faces the ceiling
(see Figure 21 on page 65 ).
6. Have a second person install two pairs of mounting screws through the bracket holes
on either side of the device to secure it to the wall.
7. Verify that the mounting screws on one side are aligned with the mounting screws on
the opposite side and that the device is level (see
Figure 21 on page 65 ).
Figure 21: SRX210 Services Gateway Wall Installation — Hanging the
Services Gateway on a Wall
Related
Documentation
SRX210 Services Gateway General Safety Guidelines and Warnings on page 115 •
• Required Tools and Parts for Installing and Maintaining the SRX210 Services Gateway
on page 47
• Preparing the SRX210 Services Gateway for Rack-Mount Installation on page 53
• Installing the SRX210 Services Gateway on a Desk on page 62
