CHAPTER 5

SRX210 Services Gateway Mini-Physical
Interface Modules

This chapter includes the following topic:

SRX210 Services Gateway Mini-Physical Interface Modules on page 33

SRX210 Services Gateway Mini-Physical Interface Modules

The SRX210 Services Gateway supports Mini-Physical Interface Modules (Mini-PIMs).

A Mini-PIM is a network interface card (NIC) that is installed on the services gateway to
provide physical connections to a LAN or a WAN. The Mini-PIM receives incoming packets
from the network and transmits outgoing packets to the network. The Mini-PIMs supported
on the services gateway are field-replaceable. The field replaceable Mini-PIMs are
removable and insertable into the device. You can install a Mini-PIM into the Mini-PIM
slot available on the front panel of the services gateway chassis.

For more information about supported Mini-PIMs and the minimum supported Junos OS
release, see SRX Series Services Gateway Interfaces Models and Compatibility

For more information about how to install and configure Mini-PIMs, refer to the

SRX Series

Services Gateways for the Branch Physical Interface Modules Hardware Guide

.

CAUTION:

The Mini-PIMs available on the SRX210 Services Gateway are not

hot-swappable. You need to power off the device before removing or installing
Mini-PIMs.

Related

Documentation

SRX210 Services Gateway Description on page 3

SRX210 Services Gateway Specifications on page 7

SRX210 Services Gateway Hardware Features on page 4

SRX210 Services Gateway Built-In Interfaces on page 11

Physical Interface Modules
