Page 103
NOTE:
Downloading of purchased licenses from the setup wizard is
available only in Junos OS Release 11.2R3 or later.
•
Configuration of a chassis cluster—Perform the initial configuration of the chassis
cluster using a console connection. Before you perform the initial configuration, connect
the built-in Ethernet ports as follows:
•
Port 0/6—Connect to the out-of-band management network for management of
the device. When you enable chassis clustering as part of configuring the chassis
cluster, the management interface (
fxp0
) is automatically created on this port.
•
Port 0/7—Connect to the other device in the chassis cluster. When you enable chassis
clustering, the control interface between the two devices (
fxp1
) is automatically
created on this port.
You must also make another connection between the two devices for the fabric link.
You can use any Fast Ethernet or Gigabit Ethernet port for this connection. You must
configure the interface you choose as the fabric link. For more information on configuring
chassis clusters, see the
Mapping the Chassis Cluster Ports
On the SRX210 Services Gateway, the
fxp1
port is not user-configurable when the services
gateway is operating in chassis cluster mode.
The
fxp0
port is dedicated as the out-of-band management interface for each of the
devices in the chassis cluster setup and the
fxp1
port is dedicated as the chassis-cluster
control port.
shows the mapping of the chassis cluster ports.
Table 33: Mapping the Chassis Cluster Ports on an SRX210 Services
Gateway
Management Interface
Ethernet Ports on SRX210 Services Gateway
fxp0 (management port)
0/6 (
fe-0/0/6
)
fxp1 (control port)
0/7 (
fe-0/0/7
)
Junos OS automatically creates the fxp0 and fxp1 interfaces on these ports when the
SRX210 Services Gateway is operating in chassis cluster mode.
For more information, see the following topics:
•
•
87
Copyright © 2013, Juniper Networks, Inc.
Chapter 15: Performing Initial Software Configuration on the SRX210 Services Gateway
