- Tenant
Displays the L-Platforms and L-Servers currently in use.
- Tenant (History)
The L-Platforms and L-Servers, including ones used in the past, are displayed.
Those that were cancelled over a year ago are no longer displayed in the history.
Point
The following describes how to find an L-Platform to display when there are a large number of L-Platforms.
1. Select the tenant in the pane on the left. When there are a large number of tenants, use the browser's "find on this page" feature
to find the tenant while the tenant list is displayed in the pane on the left.
2. Expand the tree of the tenant found in step 1, then use the browser's "find on this page" feature to find the L-Platform while
the L-Platform list is displayed.
3. From the tree at the left, select the L-Platform for which to display the system conditions.
The selected L-Platform is displayed in the CI list on the right.
If the "L-Platform" folder is selected in the tree, all L-Platforms under the folder are displayed in the CI list.
If an L-Server is selected in the tree, information about the selected server is displayed in the CI list.
The L-Platforms and L-Servers under each folder in the tree are displayed in descending order based on their update date and
time.
4. Select an L-Platform in the CI list, and then click the Show Graph button.
The system conditions is displayed in the lower part of the CI list. Refer to " 5.2.1 System Conditions Display " for details on the
displayed system conditions.
The table below explains the displayed items.
Item Explanation
Nickname Displays the display name of the configuration item.
If the CI list Nickname link is clicked, the configuration information of the target
tenant, L-Platform or L-Server is displayed in a separate window. Refer to "
5.2.2
