Note
The Running icon for a server indicates that the power has been turned on.
Even if the Running icon is displayed, login to the L-Platform may fail if logged in immediately after deployment or starting the virtual
server. In this case, allow a few minutes before trying to log in again.
Information
For a dual-role administrator, Tenant operation button is displayed.
Refer to "
Appendix C Tenant Operation by Dual-Role Administrators " for details.
9.2.2 L-Platform Detailed Information Display
Follow the steps below to display the details of L-Platform:
1. Display the L-Platform Management, L-Platform Management (list), or Server List page.
Refer to "
9.2.1 L-Platform Management Display Page " for information on how to display the page.
2. Click the Details button after selecting the L-Platform or the server required.
The L-Platform Details page will be displayed.
There are two types of display format for the L-Platform Details page below. The display format can be switched using the button
( ) located on the top right hand side of the page.
- L-Platform configuration image
By clicking the button ( ) located on the top right hand side of the page, the L-Platform configuration is displayed as
an image.
Icons displayed in the L-Platform configuration area are as follows.
