The following ports can only be specified for USP/NSC and USP V/VM:
Basic Option Option Option
CL5 an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CL6 an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CL7 an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CL8 an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CL9 an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLA an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLB an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLC an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLD an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLE an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLF an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
CLG an bn cn dn en fn gn hn jn kn ln mn nn pn qn rn
„
Target ID: Defines the SCSI/fibre target ID number of the physical volume on the
specified port. See Appendix C for further information on fibre address conversion.
„
LU#: Defines the SCSI/fibre logical unit number (LU#) of the physical volume on the
specified target ID and port.
Note: In case of fibre channel, if the TID and LU# displayed on the system are different
than the TID on the fibre address conversion table, then you must use the TID and LU#
indicated by the raidscan command in the CCI configuration file.
„
MU# for HOMRCF: Defines the mirror unit number (0 - 2) for the identical LU on the
HOMRCF. If this number is omitted it is assumed to be zero (0). The cascaded mirroring
of the S-VOL is expressed as virtual volumes using the mirror descriptors (MU#1-2) in the
configuration definition file. The MU#0 of a mirror descriptor is used for connection of
the S-VOL. SnapShot will have 64 mirror descriptions in HOMRCF and SnapShot feature.
SMPL P-VOL S-VOL
Feature MU#0-2 MU#3 – 63 MU#0-2 MU#3 – 63 MU#0 MU#1 – 63
HOMRCF valid Invalid valid Invalid valid Invalid
SnapShot valid valid valid valid valid Invalid
