284 Chapter 4 Performing CCI Operations
IRIX System with FC_AL:
# ls /dev/rdsk/*vol | ./inqraid
/dev/rdsk/dks1d6vol -> [SQ] CL2-D Ser = 30053 LDEV = 9 [HITACHI ] [OPEN-3 ]
HORC = P-VOL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 = SMPL]
RAID5[Group 2- 1] SSID = 0x0008 CTGID = 3
/dev/rdsk/dks1d7vol -> [SQ] CL2-D Ser = 30053 LDEV = 14 [HITACHI ] [OPEN-3-CM ]
RAID5[Group 2- 1] SSID = 0x0008
IRIX System with Fabric:
# ls /dev/rdsk/*/*vol/* | ./inqraid
/dev/rdsk/50060e8000100262/lun3vol/c8p0 -> [SQ] CL2-D Ser = 30053 LDEV = 9 [HITACHI] [OPEN-3]
HORC = P-VOL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 = SMPL]
RAID5[Group 2- 1] SSID = 0x0008 CTGID = 3
/dev/rdsk/50060e8000100262/lun4vol/c8p0 -> [SQ] CL2-D Ser=30053 LDEV = 14 [HITACHI] [OPEN-3-CM]
RAID5[Group 2- 1] SSID = 0x0008
OpenVMS ® System:
$ inqraid dka145-146
DKA145 -> [ST] CL2-D Ser = 30053 LDEV = 9 [HITACHI ] [OPEN-3 ]
HORC = P-VOL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 = SMPL]
RAID5[Group 2- 1] SSID = 0x0008 CTGID = 3
DKA146 -> [ST] CL2-D Ser = 30053 LDEV = 14 [HITACHI ] [OPEN-3-CM ]
RAID5[Group 2- 1] SSID = 0x0008
Figure 4.60 Inqraid Command Tool Examples
The following items are output for the inqraid command tool:
CLX-Y: Displays the port number on the RAID storage system.
Ser: Displays the production (serial#) number on the RAID storage system.
LDEV: Displays the LDEV# in the RAID storage system.
HORC: Displays the attribute (“PVOL/SVOL/SMPL”) of a volume as TrueCopy in the RAID
storage system.
HOMRCF: Displays the attribute (“PVOL/SVOL/SMPL”) of a volume as MU#0-2 of
ShadowImage/Snapshot in the RAID storage system.
Group: Displays the physical position of an LDEV according to mapping of LDEV in the
RAID storage system.
LDEV Mapping Display Formats
RAID Group RAID1[Group Group number - Sub number]
RAID5[Group Group number - Sub number]
RAID6[Group Group number - Sub number]
SnapShot SVOL SNAPS[PoolID poolID number ]
Unmapped UNMAP[Group 00000]
External LUN E-LUN[Group External Group number]
HDP (AOU) volume A-LUN[PoolID poolID number ]
SSID: Displays Sub System ID of the LDEV in the RAID storage system.
CTGID: Displays CT group ID of TrueCopy Async/UR when the LDEV has been defined as
the PVOL or SVOL of the TrueCopy Async/UR.
