Hitachi Command Control Interface (CCI) User and Reference Guide 275
4.13.10 Mount Subcommand
The mount subcommand mounts the specified drive to the specified partition on the
specified hard disk drive using the drive letter. When the mount subcommand is executed
without an argument, all currently mounted drives (including directory mounted volumes)
are displayed, and logical drive has been mounting an LDM volume then displays
Harddisk#[n] configured an LDM volume.
Table 4.43 lists and describes the mount subcommand parameters. Figure 4.56 and Figure
4.57 show examples of the mount subcommand used as an option of the pairsplit command
and its output.
Table 4.43 Mount Subcommand Parameters
Parameter Value
Command Name mount
Format -x mount
-x mount drive: hdisk# [partition#] for Windows NT
-x mount drive: Volume# for Windows 2008/2003/2000
-x mount drive: [\directory] Volume# for Windows 2008/2003/2000
Arguments drive: hdisk# [partition #]: Specifies the logical drive, hard disk drive (number), and partition to be
mounted.
drive: [\directory] Volume#: Specifies the logical drive and LDM volume name and number to be
mounted. Volume# must be specified ‘\Vol# or \Dms# or \Dmt# or \Dmr# ‘ as LDM volume for Windows
2008/2003/2000. To mount HarddiskVolumeX: -x mount C: hdX or -x mount C: \VolX
See section4.18.1 for information on ‘\Vol# or \Dms# or \Dmt# or \Dmr#’ for LDM volumes.
[\directory]: Specifies the directory mount point on the logical drive.
pairsplit -x mount D:\hd1 \Vol8
D:\hd1 <+> HarddiskVolume8
pairsplit -x mount D:\hd2 \Vol9
D:\hd2 <+> HarddiskVolume9
Restriction The partition on the specified disk drive (hard disk) must be recognized on the Windows system.
[\directory] for the mount must be specified a mount point without imbedded space character.
If [\directory] will be detected as mount point with embedded space (i.e. aaa bbb), then the directory
will be shown by adding “…” to first strings as below.
pairsplit -x mount
Drive FS_name VOL_name Device Partition ... Port PathID Targ Lun
D: NTFS Null Harddiskvolume3 ... Harddisk2
D:\aaa… NTFS Null Harddiskvolume4 ... Harddisk3
The same method is used for “inqraid $LETALL” and “raidscan -pi $LETALL -find” command.
pairsplit -x mount F: hdisk2 p1 -x mount G: hdisk1 p1
pairsplit -x mount
Drive FS_name VOL_name Device Partition ... Port PathID Targ Lun
C: FAT Null Harddisk0 Partition1 ... 1 0 0 0
F: FAT Null Harddisk2 Partition1 ... 2 0 5 1
G: NTFS Null Harddisk1 Partition1 ... 2 0 5 0
Z: CDFS Null CdRom0 ... Unknown
Figure 4.56 Mount Subcommand Example for Windows NT
