272 Chapter 4 Performing CCI Operations
4.13.8 Portscan Subcommand
The portscan subcommand displays the devices on the specified port(s). Table 4.41 lists and
describes the portscan subcommand parameters. Figure 4.53 shows an example of the
portscan subcommand used as an option of the raidscan command and its output.
Table 4.41 Portscan Subcommand Parameters
Parameter Value
Command Name portscan
Format -x portscan port#(0-N)
Argument port#(0-N): Specifies the range of port numbers on the Windows system.
raidscan -x portscan port0,20
PORT[ 0] IID [ 7] SCSI Devices
PhId[ 0] TId[ 3] Lun[ 0] [MATSHIT] [CD-ROM CR-508 ] ...Claimed
PhId[ 0] TId[ 4] Lun[ 0] [HP ] [C1537A ] ...Claimed
PORT[ 1] IID [ 7] SCSI Devices
PhId[ 0] TId[ 0] Lun[ 0] [HITACHI ] [DK328H-43WS ] ...Claimed
PORT[ 2] IID [ 7] SCSI Devices
PhId[ 0] TId[ 5] Lun[ 0] [HITACHI ] [OPEN-3 ] ...Claimed
PhId[ 0] TId[ 5] Lun[ 1] [HITACHI ] [OPEN-3 ] ...Claimed
PhId[ 0] TId[ 5] Lun[ 2] [HITACHI ] [OPEN-3 ] ...Claimed
PhId[ 0] TId[ 6] Lun[ 0] [HITACHI ] [3390-3A ] ...Claimed
Note: This example displays the devices for the range of ports from 0 to 20.
Figure 4.53 Portscan Subcommand Example
Output of the portscan subcommand:
„
Port: Shows the port number on the device adapter recognized by the Windows system
„
IID: Shows the initiator ID on the specified device adapter port
„
Phid: Shows the BUS number on the specified device adapter port
„
Tid: Shows the target ID of the hard disk(s) on the specified adapter port and bus. For
further information on fibre-to-SCSI address conversion, see Appendix C.
„
LUN: Shows the LU number of each hard disk on the specified device adapter port/bus.
This item shows LDEV# of the partner who becomes a pair in or among the RAID storage
system.
