MEASURE RECTANGLE OUTSIDE (Cycle 424, DIN/ISO: G424,
software option 17)
16.8
16
TNC 620 | User's Manual Cycle Programming | 5/2013
379
Tolerance for center 2nd axis Q280: Permissible
position deviation in the minor axis of the working
plane. Input range 0 to 99999.9999
Measuring log Q281: Define whether the TNC
should create a measuring log:
0 : Do not create a measuring log
1 : Create a measuring log: The TNC saves the log
file TCHPR424.TXT as standard in the directory
TNC:\.
2 : Interrupt program run and output measuring log
to the TNC screen. Resume program run with NC
Start.
PGM stop if tolerance error Q309: Definition of
whether in the event of a violation of tolerance
limits the TNC is to interrupt program run and output
an error message:
0 : Do not interrupt program run, do not output an
error message
1 : Interrupt program run and output an error
message
Tool for monitoring Q330: Definition of whether
the TNC is to monitor the tool (See "Tool
monitoring", page 360). Input range 0 to 32767.9,
alternatively tool name with maximum of 16
characters
0 : Monitoring inactive
>0 : Tool number in the tool table TOOL.T
