3. Menu Operation DD35 Production Switcher
3 – 129 Operating Instructions – Rev. 16 / 10.2001
Flat matte 1 selects matte 1 as output.
Flat matte 2 selects matte 2 as output.
Selecting Wash serves to select a matte that is composed of a color wash between
matte 1 and matte 2.
If only the wash button lights up, it is possible to change the color wash individually
with the Softness, Position, and Angle controls.
The Softness control permits adjusting the width of the transition between the two
colors. The Position control serves to shift the position of the transition. With the
Angle control, the transition angle can be rotated.
Select Matte 1 or Matte 2 if you wish to adjust the matte with the Hue, Chroma,
and Luminance controls. Select Wash (upper row) to adjust Softness, Position,
and Angle.
Selecting a special matte composed of matte 1 + 2. The contents of the Texture
Store washes between them.
For details refer to section Introduction.
Flat Matte 1
Flat Matte 2
Wash
Texture Wash
Digits
