9424200996 Rev L 499
Figure 316. Analog Inputs - Voltage Input Connections
Figure 317. Analog Inputs - Current Input Connections
External RTD Input Connections
External 2-wire RTD input connections are shown in Figure 318. Figure 319 shows external 3-wire RTD
input connections.
Figure 318. External Two-Wire RTD Input Connections
AIN I+
AIN –
AIN V+
RTD Module
P
0
0
6
1
-3
8
0 – 10 Vdc
Voltage
Transducer
AIN I+
AIN –
AIN V+
RTD Module
P
0
0
6
1
-3
9
4 – 20 mA
Current
Transducer
RTD1+
RTD1–
RTD1C
RTD Module
Jumper
P
0
0
6
1
-4
0
BLACK
RED
BE1-11m RTD Module
