Maps and Registers
ATCA-7365 Installation and Use (6806800K65N)
223
6.4.21 NMI Status and Control Register
The following table provides a detailed description about NMI Status and Control Register.
6.4.22 Telecom Clock Supervision Registers
6.4.22.1 Telecom Clocking Status Registers
The telecom backplane clocking status register indicates when the backplane input clock
signals are toggling.
Table 6-74 NMI Status and Control Register
Address Offset: 0x58
Bit
Description
Default
Access
0
Diagnostic NMI Status
0
LPC: r/w1c
IPMC: r/w
1
Diagnostic NMI Status
0
LPC: r
IPMC: r/w
2
Watchdog NMI Status
0
LPC: r/w1c
IPMC: r/w
3
Watchdog NMI Status
0
LPC: r
IPMC: r/w
7:4
Reserved
0
r
Table 6-75 Telecom Backplane Clocking Status Register
Address Offset: 0x66
Bit
Description
Default
Access
0
0: CH1_CLK1A_IN is static or period is not in the correct
range.
1: CH1_CLK1A_IN is toggling
PWR_GOOD:0
LPC: r
1
0: CH1_CLK1B_IN is static or period is not in the correct
range.
1: CH1_CLK1B_IN is toggling
PWR_GOOD:0
LPC: r
