ReFlex Power™ Programming Manual
AC Module Remote Programming
90
M380056-03 Rev L
•
Programmable configuration: stand alone, parallel or phase group
R
EADBACK
F
UNCTIONS
•
Measure voltage, current, frequency, and phase
•
Voltage, current and frequency settings (phase, if in a phase group)
•
Soft voltage and current limits
•
Over/Under Voltage and Over Current protection setting
•
Status and Accumulated Status registers
•
Programming error codes
•
Fault codes
•
Manufacturer, power supply model, serial number, and firmware
version identification
4.3
POWER-ON CONDITIONS
Table 4-1 presents remote power-on conditions for the AC Power Supply.
Table 4-1. Remote Power-On Conditions
Condition
Default
Voltage
0 Volts (initial power–on voltage). Also see CAL
Current
7.140 Amps (initial power–on current). Also see CAL
Frequency
60 Hz
OVP Trip Voltage
154 V (110% of Module Maximum Voltage, which is 140 V) +7% (initial power–
on OVP). See CAL
Output
OFF
Parallel
No Modules Paralleled
Voltage Range
Low
Phase
0.0 degrees, stand alone mode
OCP Trip Current
7.42 A (Maximum current 102% of the full scale current, which is 7 A for low
voltage range)
