DC Module Remote Programming ReFlex Power™ Programming Manual
M380056-03 Rev L 65
3.11 STATUS SCPI COMMANDS
3.11.1 STATUS SCPI C OMMAND S UMMARY
STATus[n]
:MODE
:DELAY <0+NR1>
:DELAY?
:MODule
:ENABles <0+NR1>
:ENAB?
:FAULts?
3.11.2 STATUS SCPI C OMMAND R EFERENCE
Command Description
STATus Status subsystem. Module ‘n’.
:MODE:DELAY <0+NR1> Sets the delay timer for responding to a status change from CV
to CC mode. Value in counts: 0 to 255, of approximately 20ms
for each count. Delay counter is immediately reloaded when the
mode switches back to CV. Default timer value is 0.
:MODE:DELAY? Returns the CV to CC status delay timer value. *RST sets to 0.
:MODule
:ENABles<0+NR1> Enable supervisory. See Table 3-3 for enable values.
:ENABles? Query the enabled supervisories
:FAULts? Query the module faults
Table 3-3. DC Fault and Enable Register
Bit Hex Value Mnemonic Description
0 0x00000001 LDF Line Drop Fault
1 0x00000002 RSF Reverse Sense Fault
2 0x00000004 OCP Over Current Fault
3 0x00000008 OVP Over Voltage Protection Fault
4 0x00000010 ROCP Redundant Over Current Protection Fault
5 0x00000020 ROVP Redundant Over Voltage Protection Fault
6 0x00000040 UVP Under Voltage Protection Fault
7 0x00000080 RESERVED
8 0x00000100 IMPTEMPHSK1 Heatsink1 Temperature is Warm
9 0x00000200 IMPTEMPHSK2 Heatsink2 Temperature is Warm
10 0x00000400 OVTEMPHSK1 Heatsink1 Temperature Exceeds Limit
11 0x00000800 OVTEMPHSK2 Heatsink2 Temperature Exceeds Limit
12 0x00001000 AFF Air Flow Fault
13 0x00002000 UVP5V Internal 5V Under Voltage Fault
14 0x00004000 OVP5V 5V Over Voltage Fault
