ReFlex Power™ Programming Manual Controller Module Remote Programming
38 M380056-03 Rev M
2.8.1 P ARAMETER D EFINITIONS
Table 2-3. Parameter Definitions
Type Valid Arguments
1 or “ON”; 0 or “OFF”
The data format is defined in IEEE-488.2 for integers.
Zero, positive and negative integer numeric values are valid data.
<0+NRi> Zero and positive integer numeric values.
<-NRi> Negative integer numeric values.
The data format is defined in IEEE-488.2 for flexible Numeric Representation.
Zero, positive and negative floating point numeric values are some examples of valid data.
<+NRf> Positive non-zero floating point numeric values.
<0+NRf> Zero and positive floating point numeric values.
<-NRf> Negative floating point numeric values.
Text characters enclosed by double quotes.
Text characters with no quotes.
The address number of the module in the RFP chassis system.
Note: Channel number 0 is invalid for any auxiliary device, because the
ReFlex Power™ implementations of the SCPI language reserves channel 0
for the “global” address to address all channels.
2.8.2 N UMERIC D ATA D IMENSIONAL U NITS
The Ethernet interface accepts these dimensional units for numeric values of
parameters as listed below. For example, the command
SOUR:VOLT 115
programs 115.0 volts when setting the output voltage of the supply.
Table 2-4. Numeric Data Units
Parameter Dimensional Unit
Voltage Volt
Current Ampere
Time Seconds
Frequency Hertz
Phase Angle Degrees
2.8.3 C ONVENTIONS
Optional keywords and parameters are enclosed by left and right square
brackets: [ ]. The parameter , in a command, indicates the address
number of the module being commanded.
•
Discrete module numbers are separated by commas: .
