Load Module Remote Programming ReFlex Power™ Programming Manual
M380056-03 Rev L 121
Table 5-2. LD Fault and Enable Register
Bit Hex Value Mnemonics Description
0 0x00000001 PRST Power On Reset
1 0x00000002 FLS Module Fault Latch Set
2 0x00000004 GPRF Group Fault
3 0x00000008 MDENA Module Front Panel Enable
4 0x00000010 BCKRI Backplane Remote Inhibit
5 0x00000020 OVP Over Voltage Protection Fault
6 0x00000040 ROVP Redundant Over current Fault
7 0x00000080 UVP Under Voltage Protection Fault
8 0x00000100 OCP Over current Fault
9 0x00000200 ROCP Redundant Over current Fault
10 0x00000400 RSF Remote Sense Fault
11 0x00000800 ITOPP Input Transient Overpower Protection
12 0x00001000 NEGPOL Input Negative Polarity Voltage
13 0x00002000 REVOVP Input Reverse Over voltage
14 0x00004000 AMA;PG Analog Fault
15 0x00008000 PIOPP Program Over Power Protection
16 0x00010000 IOTP Internal Impending Over temperature
17 0x00020000 OTP Internal Over temperature
18 0x00040000 AFF Airflow Fault
19 0x00080000 UV5V 5V Housekeeping Supply Under voltage
20 0x00100000 OV5V 5V Housekeeping Supply Over voltage
21 0x00200000 UV14PT2V 14.2V Housekeeping Supply Under voltage
22 0x00400000 OV14PT2V 14.2V Housekeeping Supply Over voltage
23 0x00800000 UVNEG15V -15V Housekeeping Supply Under voltage
24 0x01000000 OVNEG15V -15V Housekeeping Supply Over voltage
25 0x02000000 GNDF Paralleling Ground Fault
26 0x04000000 OCLF Outer Control Loop Fault
27 0x08000000 ICLF Inner Control Loop Fault
28 0x10000000 RESERVED
29 0x20000000 RESERVED
30 0x40000000 RESERVED
31 0x80000000 RESERVED
5.11 SYSTEM SCPI COMMANDS
5.11.1 SYSTEM SCPI C OMMAND S UMMARY
SYSTem
:GROup
:DEFine
:PARallel
:DELete
:DELETE:ALL
:ERRor?
