AC Module Remote Programming

ReFlex Power™ Programming Manual

M380056-03 Rev L

107

Table 4-2. AC Faults and Enables Register 0

Bit

Hex Value

Mnemonics

Description

31-27

RESERVED

26

0x04000000

IOTP4

Impending Over Temperature – 4 Fault

25

0x02000000

IOPT3

Impending Over Temperature –3 Fault

24

0x01000000

OTP4

Over Temperature –4 Fault

23

0x00800000

OTP3

Over Temperature –3 Fault

22

0x00400000

BCKRI

Back Plane remote inhibit

21

0x00200000

IOCP

Inrush Over Current

20

0x00100000

DCUVP

DC Bus Under Voltage Protection

19

0x00080000

DCOVP

DC Bus Over Voltage Protection

18

0x00040000

SYNCF

Synchronization Fault

17

0x00020000

DCP

DC protection Fault

16

0x00010000

IIPK

Inverter Peak Over Current

15

0x00008000

UVP12

Under Voltage Plus 12 Volt Fault

14

0x00004000

OVP5

Over Voltage Plus 5 Volt Fault

13

0x00002000

UVP5

Under Voltage Plus 5 Volt Fault

12

0x00001000

AFF

Air Flow Fault

11

0x00000800

OTP2

Over Temperature –2 Fault

10

0x00000400

OTP1

Over Temperature –1 Fault

9

0x00000200

IOTP2

Impending Over Temperature –2 Fault

8

0x00000100

IOTP1

Impending Over Temperature –1 Fault

7

0x00000080

DES_MODE Desired Mode – CC/CV switch mode Fault

6

0x00000040

UVP

Under Voltage Fault

5

0x00000020

ROVP

Redundant Over Voltage Fault

4

0x00000010

ROCP

Redundant Over Current Fault

3

0x00000008

OVP

Over Voltage Fault

2

0x00000004

OCP

Over Current Fault

1

0x00000002

ADC

ADC Timing Fault

0

0x00000001

LDF

Line Drop fault

Table 4-3. AC Faults and Enables Register 1

Bit

Hex Value

Mnemonics

Description

16-31

RESERVED

15

0x00008000

AUXF

Auxiliary Relay Fault

14

0x00004000

ANALOG

Analog Fault

13

0x00002000

RESERVED

12

0x00001000

RESERVED

11

0x00000800

MDENA

Front Panel Module Enable False

10

0x00000400

GPRF

Group Fault

9

0x00000200

PRST

Power Reset

8

0x00000100

PRIENA

Under/Over Voltage on PFC Bus

7-4

RESERVED

3

0x00000008

GNDF

Ground Fault

2

0x00000004

OVM12

Over Voltage Minus 12 Volts Fault

1

0x00000002

UVM12

Under Voltage Minus 12 Volts Fault

0

0x00000001

OVP12

Over Voltage Plus12 Volts Fault
