ReFlex Power™ Programming Manual AC Module Remote Programming
108 M380056-03 Rev L
4.11 SYSTEM SCPI COMMANDS
4.11.1 SYSTEM SCPI C OMMAND S UMMARY
SYSTem
:ERRor?
4.11.2 SYSTEM SCPI C OMMAND R EFERENCE
Command Description
SYSTem SYSTEM subset of SCPI command sets
:ERRor?
Returns the last error logged in the Error/Event Queue. If there are no errors,
0, No error is returned.
4.12 EXAMPLE SCPI COMMANDS TO SET PHASE AND
PARALLEL GROUPS
4.12.1 E XAMPLES C REATING A P HASE G ROUP
EXAMPLE 1: Set the group using 3 AC module (units at slot 4, 8,12)
Slot 4, Module will become master of the phase group and the slot 8 and 12 units will be the
slaves of the phase group. Default phase angle for the slot 4 = 0 degrees, slot 8 = 120
degrees and slot 12 = 240 degrees.
SYSTem:GROup:DEFine:PHASe 4,8,12 // Command to form the phase group.
SYSTem:GROup:CAT:PHASe? // Query the group
OUTP1004:STATE 1 // Turn on all the units as a group
*OPC1004? // Send next command after a ‘1’ is returned
SOUR1004:VOLT 125 // Set the group to 125 volts
*OPC1004? // Send next command after a ‘1’ is returned
SOUR1004:CURR 3 // Set all the modules to 3 Amps
*OPC1004? // Send next command after a ‘1’ is returned
SOUR12:PHASE 220 // Set the slot 12 AC module to 220 degree phase
SOUR8:PHASE 100 // Set the slot 8 AC module to 100 degree phase
*OPC12? // Send next command after a ‘0’ is returned
*OPC8? // Send next command after a ‘0’ is returned
SOUR4:PHASE -20 // Set the phase of slot 4 unit to -20 degree and
execute a synchronous phase change on all three
units.
*OPC4? // Send next command after a ‘1’ is returned
