ReFlex Power™ Programming Manual AC Module Remote Programming
102 M380056-03 Rev L
4.9.2 SOURCE SCPI C OMMAND R EFERENCE
Command Description
SOURce SOURCE subset of SCPI command sets.
:CURRent
1
[]
Sets the output current setpoint in a range 0 – 102% of maximum current for
specific voltage range. Default current set point is 102% of maximum current
for specific voltage range. The *RST command resets the Current to the
default setpoint.
:CURRent? Returns the present output current setpoint.
:MODE? Query CC/CV mode: 1 = CC, 0 = CV
:PROTection
1
[]
Sets the output current protection setpoint. Default current protection setpoint
is 106% of the maximum current for the specific voltage range.
The reset command sets the default current protection set point.
:PROTection? Returns the present output current protection set point.
:TIMER
Set Over Current Protection Hold-Off Timer. By default this value is set to
500 mSec. Valid range is 1–500 in mSec.
:TIMER? Query the value of Over Current Protection Hold-Off Timer
:TCONstant
Sets Over Current / Inrush Over Current Protection IIR Filter Time Constant
( OCP/IOCP IIR Time Constant).
The default value is 100 mSec, valid range is 20–250 in mSec.
:TCONstant? Query OCP/IOCP IIR Filter Time Constant value
:INRushcurr
:PROTection
1
Sets Inrush Over Current Protection
( 0-144% of full current )
:PROTection? Query Inrush Over Current Protection
:FREQuency Sets the output frequency set point of the present source.
:FREQuency? Returns the output frequency setpoint.
:PHASe
1
Sets the phase angle offset for the module, with respect to the Phase
Reference. Counterclockwise phase or rotation is the default; therefore the
phase angle offset is lagging the reference. The Phase Group Master must
be set last.
:PHASe? Returns the present phase angle offset.
:LEAD
2
Set the specified module to be leading the reference.
:LAG
2
Set the specified module to be lagging the reference.
:MODE
Arg 1; Constant Current (CC) and Constant Voltage (CV) operation with
automatic transitions (Auto) as determined by the load. The output will be
regulated to their respective setpoints. Arg 0; Constant Voltage mode
operation only, with CC mode disabled. Only the output voltage will be
regulated to its setpoint. The Current setpoint is ignored. Arg CC: Constant
Current mode, Voltage setpoint is ignored,
In both modes, all Voltage and Current related protection supervisories,
(OVP, OCP, ...) are functional.
:MODE? Query Operation mode, 1 = Auto, 0 = CV only mode, 3 = CC only mode
:VOLTage
1, 3
Sets the output voltage setpoint (0 – 102%).
:VOLTage? Returns the present output voltage set point.
:RANGe
Sets the voltage range of the unit to either High (1) or Low (0) voltage range.
Default voltage range of the unit is Low.
Can only be changed when output state is OFF.
Reset command sets the voltage range to default.
