DC Module Remote Programming
ReFlex Power™ Programming Manual
M380056-03 Rev L
75
During the execution of a LIST, only query commands are acceptable;
setpoint commands may generate errors or cause improper LIST execution.
List creation can only occur in standalone mode.
Information and requirements of Module operation during List creation and
execution include:
•
The maximum size allowed for a single list is 2040 entries.
•
Each SCPI command may translate to 1 or as many as 10 entries
depending on the command.
•
The current size of a list can be queried during LIST creation by using
the LIST
•
Lists can be saved in non-volatile memory and recalled by using the
name of the list.
•
When a LIST is being created in a module, the module is placed in a
special mode. This mode inhibits actual relay operation, to minimize
any chance of energizing an external load.
•
The output relays are inhibited from closing on STATE ON
commands, and RAMP commands go from start point to endpoint with
no delay.
•
Trigger output, WAIT and DWELL commands are compiled, but not
executed.
•
Any triggers that are received during the execution of a LIST:RAMP or
LIST:DWELL command are ignored.
•
Setpoint commands are executed.
•
All query commands except actual relay states and MEAS:CURR are
fully functional.
•
During the execution of a LIST, only query commands are safe.
•
During LIST creation, non-LIST commands may interact with the LIST
to generate commands to automatically control the supply.
•
If Tracking is ON, (OVP, OCP, UVP) their setting changes will
automatically be included in the LIST commands for simple setpoint
changes.
•
Tracking modes do NOT function properly with RAMP commands,
and may generate errors if attempted when a ramp is executed.
Tracking modes must be turned off and OVP, OCP, and UVP set to
proper values for the specific RAMP command, else faults may occur.
After the RAMP command and new setpoints have been issued,
tracking may be then turned back on.
•
In List mode, all relay operation should always be coordinated with the
STATE command by using the OUTP:ISOL/SENSE:DEF commands.
•
characters in length, no path/file extension is allowed.
