DC Module Remote Programming ReFlex Power™ Programming Manual
M380056-03 Rev L 79
Source Trigger commands allow a voltage and/or current setpoint to be delayed for
later application. The trigger latency is on the order of 10-20 mSec. If multiple
voltage or current commands are received, the earlier ones of each type will be
overwritten, without error. These setpoints are not retriggerable.
Table 3-8. Software Triggered Setpoints
Setpoints Description
SOUR:VOLT:TRIG Setup for a deferred SOUR:VOLT command
SOUR:VOLT:TRIG? Query returns pending Voltage setting, -0.0 if inactive
SOUR:CURR:TRIG Setup for a deferred SOUR: CURR command
SOUR:CURR:TRIG? Query returns pending Current setting, -0.0 if inactive
TRIG:TYPe 0 = VOLT, 1 = CURR, 2 = Both, Apply the setpoints
3.13.2 V OLTAGE AND C URRENT S OFTWARE R AMPS C OMMAND
S UMMARY
SOURce
:VOLTage
:RAMP ,,
:CURRent
:RAMP ,,
:VOLTCURR
:RAMP ,,,
SOURce
:VOLTage
:RAMP
:TRIGger ,,
:TRIGger?
:CURRent
:RAMP
:TRIGger ,,
:TRIGger?
:VOLTCURR
:RAMP
:TRIGger ,,,
:TRIGger?
TRIGger
:TYPe 3
:ABORt
Voltage and Current ramps can be setup and invoked on a software basis, these
commands use the same hardware that is used for LIST/TRIGGER functions, so
these functions cannot be used or intermixed at the same time. Issue a
LIST:CLOSe command to reset the LIST/TRIGGER subsystem when usage of
these commands is done.
