ReFlex Power™ Programming Manual

AC Module Remote Programming

M380056-03 Rev L

:PHASe

:PHASe?

:FREQuency

:FREQuency?
:DEFault

:MODule

:LASTCAL

:LASTCAL?

:NEXTCAL

:NEXTCAL?

4.6.2

CALIBRATION

SCPI

OMMAND

EFERENCE

Command

Description

CALibration

Calibration subset of SCPI command sets

:MEASure

:IADC

Current ADC

:OFFSET:CALC

Calibrate the current ADC offset.

:OFFSET?

Query the offset of the current ADC

:VADC

Voltage ADC

:OFFSET:CALC

Calibrate the Voltage ADC offset.

:OFFSET?

Query the offset of the Voltage ADC

:VLOCAL

Local Voltage

:OFFSET?

Query the offset of the local Voltage

:ILOCAL

Local current

:OFFSET?

Query the offset of the local current

:VREMOTE

Remote Voltage

:OFFSET?

Query the offset of the Remote Voltage

:OFFSET:CALC

Calibrate the offset of the VLOCAL,ILOCAL and VREMOTE

:CALPOTS

Analog gain and offset pots

:GAIN

This is an 8 bit value ( 0 to 255)

:START

Start the gain calpot calibration

:CURRent

Enter the floating point AC current value

:CALC

Calibrate the gain calpot

:GAIN?

Query the gain calpot set value.

:CALMON

Set the MUX for the current A2D

:CALMON?

Query current A2D MUX

:OFFSET:CALC

Calibrate the offset pot

:OFFSET?

Query the set point of the offset pot

:A2D?

Query current A2D value

:UNLock

Unlock the calibration data file; enables storage of the
calibration constants. The enable string is <“6867”>.

:STORE

Store the calibration or module data

:LOCK

Lock the files

:OUTPUT

:DCLOOP

Set the DCLOOP on or off. ON or 1 = turn on the DCLOOP
and OFF or 0 = Turn off the DCLOOP
