STARTUP Form for Reznor
®
MAPS
®
Units
Applies to:
MAPS III&IV Model Series RCB, RDB, RDCB, RDDB, RECB, REDB,
RCC, RDC, RDCC, RDDC, RECC, and REDC
STARTUP FORM
Job Name
Contractor
Verify shipping brackets are removed.
Inspect unit for damage. (I-MAPS, Sec. 3.1)
Inspect dampers.
Check condensate connections. (I-MAPS, Sec. 6.5)
Verify inlet air filters are installed.
Verify all copper tubing is isolated and does not rub.
Check for manual resets (firestat, high
gas pressure switch)
Check outside air hood and filters. (I-OPT-WH)
Check and tighten all electrical terminals.
Check clearances (I-MAPS, Sec. 4.1)
Blower
Assembly
Alignment
Belt tension
Rotation
Motor HP
Seal electrical entrances.
Nameplate Amps
RPM
E.S.P.
L1 - L2
L2 - L3
L3 - L1
RLA-1
RLA-2
RLA-3
Startup Checklist - General Checks (Reference)
Condenser
Fans
Nameplate HP
Volts
RLA
Fan 1
Fan 2
Fan 3
L2 - L3
L3 - L1
RLA-1
RLA-2
Fan 4
RLA-3
Compressor
Data
Outdoor Air Conditions:
Entering Dry Bulb
Entering Wet Bulb, Dewpoint, or % RH
Circuit
Compressor A
Compressor B
Compressor C
D or Reheat DH
RLA-3
RLA-2
RLA-1
L3 - L1
L2 - L3
L1 - L2
Nameplate
RLA
Head Press
PSIG
Suct Press
PSIG
Superheat
DAT
Subcooling
Street
City, ST, Zip
Date
Contact
Model
Serial No.
Gas Heat Section
Leak test gas piping
Purge air from lines
Inlet Gas Pressure
Maximum Inlet Gas Pressure: 14" w.c.
Operational Inlet Gas Pressure
Minimum Inlet Gas Pressure: 6.0"w.c.
Check Manifold Pressure (Desired outlet pressure
of single manifold or first manifold with two heat
sections at full fire is 3.7" w.c. Desired outlet
pressure of second manifold on unit with two heat
sections is 3.6" w.c.
Operational Manifold Gas Pressure:
All "C" Cabinets and "D" Cabinets
with one Heat Section
Second manifold on D Cabinet
with Heat Section Sizes 1000,
1200, 1400, and 1600
Electric
Heat
Section
Voltage
Option
ERV
Exhaust
Assy
Alignment
Belt tension
Air balance
L1 - L2 L2 - L3 L3 - L1 RLA-1 RLA-2 RLA-3
Intake Motor HP
Nameplate Amps
Nameplate Amps
Exhaust Mtr HP
Motor
Intake
Exhaust
Comments
L1 - L2
Check discharge and space sensors.
Check all fans for free movement.
Check for voltage imbalance.
(I-MAPS, Sec. 7.2)
Tighten all screws on pulleys, bearings,
and fans (I-MAPS, Sec. 6.6)
Check optional dirty filter
switch. (I-MAPS, Sec. 8.1)
Check optional hot gas bypass valve. (I-MAPS, Sec. 7.7)
Phone
Size
Tag
Check fuses/breakers for correct
sizing (Check unit rating plate for
electrical requirements.)
CFM.
Voltage
Amperage
Amperage
Voltage
Amperage
Voltage
Voltage
Amperage
Amperage
L3 - L1
L2 - L3
L1 - L2
RLA-3
RLA-2
RLA-1
1
2
3
4
Print Form
Reset Form
