Cabinet
Size
RCB/RCC Model Size
RDB/RDC Model Size
Codes - FIG 8C
X
Y
Outside Curb Dimensions for Cooling Models RCB/RCC/RDB/RDC with Energy Recovery
Module by Cabinet Size, Model Size - inches (±1/8)
A
060, 078, 090, 118, 120, 136 084, 102, 114, 142, 144, 162
38-5/8 136-3/4
B
160, 186, 200
184, 196, 210, 222, 224, 236, 257 53-5/8 136-3/4
C
190, 216
248, 262, 272, 288
65-1/8 171-5/8
298, 410
354, 370, 468, 482
65-1/8 171-5/8
Outside Curb Dimensions for Cooling Models RCB/RCC/RDB/RDC with Energy Recovery
Module by Cabinet Size, Model Size - mm (±3)
A
060, 078, 090, 118, 120, 136 084, 102, 114, 142, 144, 162
981
3473
B
160, 186, 200
184, 196, 210, 222, 224, 236, 257 1362
3473
C
190, 216
248, 262, 272, 288
1654
4359
298, 410
354, 370, 468, 482
1654
4359
Cabinet
Size *
RDCB/RDCC
Model Size*
RDDB/RDDC Model Size*
Gas Heat
Size *
Codes - FIG 8C
X
Y
Curb Dimensions for Cooling/Gas Heat Makeup Air Model RDCB, RDCC, RDDB, RDDC with
Energy Recovery Module by Cabinet Size and Model Size - inches (±1/8)
A
060, 078, 090, 118,
120, 136
084, 102, 114, 142
100
38-5/8 136-3/4
084, 102, 114, 142, 144, 162
150
38-5/8 136-3/4
200
38-5/8 136-3/4
B
078, 090, 118, 120,
136, 160, 186, 200
102, 114, 142, 144, 162, 184,
196, 210, 222, 224, 236, 257
250
53-5/8 136-3/4
300
53-5/8 136-3/4
C
190, 216, 298, 410 248, 262, 272, 284, 354, 370,
468, 482
400
65-1/8 171-5/8
500
65-1/8 171-5/8
600
65-1/8 171-5/8
700
65-1/8 171-5/8
Curb Dimensions for Cooling/Gas Heat Makeup Air Model RDCB, RDCC, RDDB, RDDC with
Energy Recovery Module by Cabinet Size and Model Size - mm (±3)
A
060, 078, 090, 118,
120, 136
084, 102, 114, 142
100
981
3473
084, 102, 114, 142, 144, 162
150
981
3473
200
981
3473
B
078, 090, 118, 120,
136, 160, 186, 200
102, 114, 142, 144, 162, 184,
196, 210, 222, 224, 236, 257
250
1362
3473
300
1362
3473
C
190, 216, 298, 410 248, 262, 272, 284, 354, 370,
468, 482
400
1654
4359
500
1654
4359
600
1654
4359
700
1654
4359
Cabinet
Size*
RECB/RECC
Model Size *
REDB/REDC Model
Size *
* Electric
Heat Size
Codes - FIGURE 8C
X
Y
Curb Dimensions for Cooling/Electric Heat Makeup Air Model RECB, RECC, REDB, REDC
by Cabinet Size and Model Size - inches (±1/8)
A
060, 078, 090, 118,
120, 136
084, 102, 114, 142,
144, 162
All
available
38-5/8
136-3/4
B
078, 090, 118, 120,
136, 160, 186, 200
084, 102, 114, 142, 144,
162, 184, 196, 210, 222,
224, 236, 257
53-5/8
136-3/4
C
190, 216, 298,
410
248, 262, 272, 288,
354, 370, 468, 482
65-1/8
171-5/8
Curb Dimensions for Cooling/Electric Heat Makeup Air Model RECB, RECC, REDB, REDC
by Cabinet Size and Model Size - mm (±3)
A
060, 078, 090, 118,
120, 136
084, 102, 114, 142,
144, 162
All
available
981
3473
B
078, 090, 118, 120,
136, 160, 186, 200
084, 102, 114, 142, 144,
162, 184, 196, 210, 222,
224, 236, 257
1362
3473
C
190, 216, 298,
410
248, 262, 272, 288,
354, 370, 468, 482
1654
4359
5.4.1.2 Roof Curb Option CJ34 for MAPS
®
III&IV, Cabinets A, B, & C with ER Module (cont'd)
5.4 Mounting on a Roof Curb (cont'd)
5.0 Mounting
(cont'd)
5.4.1 Downflow Roof Curbs for MAPS
®
III Cabinets A, B, C (cont'd)
Option CJ50 is a 32" (813mm) high horizontal airflow curb for MAPS
®
III&IV, Cabinet
Sizes A and B. Option CJ49 is a 36" (914mm) high horizontal airflow curb for MAPS
®
III
&IV, Cabinet Size C.
Option CJ54 is a 32" (813mm) high horizontal airflow curb for MAPS
®
III&IV, Cabinet
Sizes A and B with an energy recovery module. Option CJ53 is a 36" (914mm) high
horizontal airflow curb for MAPS
®
III&IV, Size C with an energy recovery module.
Verify all the components and be sure that the curb is correct for the system being
installed.
5.4.2 Roof Curbs for
Horizontal Airflow
(Options CJ49, CJ50,
CJ53, and CJ54) -
Cabinets A, B, and C
NOTE: Horizontal flow curbs
in this section do not apply
to a MAPS
®
unit with an
optional energy recovery
module. For a horizontal
airflow curb for a MAPS
®
unit with an energy recovery
module (Option ER1), go to
Paragraph 5.4.2.2 page 19.
Components and Application
If area inside curb is open, roof opening dimensions
MUST be no greater than:
Cabinet A - 34-13/16"x133" (884x3378mm);
Cabinet B - 49-13/16"x133" (1265x3378mm);
Cabinet C - 61-5/16"x167-7/8" (1557x4264mm).
When cutting only duct openings, cut opening 1" (25mm)
larger than duct size to allow clearance for installation.
Approximate Weights of
Roof Curb Option CJ34
by Cabinet Size *
Cabinet
A
Cabinet
B
Cabinet
C
lbs
254
292
365
kg
115
132
166
*See Model Size / Cabinet Size Cross Reference on pages 71-72.
5.4.2.1 Horizontal
Airflow Roof Curb
Option CJ49 for
MAPS
®
III&IV Cabinets
A, & B and Option CJ50
for Cabinet C
Roof Curb P/N's by Model & Cabinet Size *
Cabinet A
Cabinet B
Cabinet C
Models RCB/RCC/RDB/RDC
*All Sizes
*All Sizes
*All Sizes
Models RDCB/RDCC/RDDB/RDDC with Cabinet
& Gas Heat Size Combination
With Gas Heat
Sizes 100/150/200
With Gas Heat
Sizes 250/300
With Gas Heat Sizes
400/500/600/700/1000
Models RECB/RECC/REDB/REDC
*All Sizes
*All Sizes
*All Sizes
ID on
Part
Roof Curb Package P/N (Option)
261699 (CJ50) 261700 (CJ50)
261701 (CJ49)
Component Descriptions
Qty
Component P/N's
A
Curb End Assembly (solid)
1
261653
261654
261670
B
Curb Side Assembly (insulated)
2
261655
261671
3 C's
Curb End Assembly (insulated)
1
261656
261657
261672
Duct Flanges (4pcs in one bundle)
4
261386
261387
261414
Return Air Cap (not used with return air)
1
261388
261389
261415
D
Supply Duct End (solid insulated partition)
1
261658
261659
261673
E
Supply Duct Bottom (insulated) (**2 pcs)
**1
261660
261661
** 261674 & 261428
F
Supply Air Duct Bottom Liner (**2 pcs)
**1
261394
261395
** 261418 & 261429
G
Air Baffle ("curve" in the supply duct)
1
268604
268605
268606
H
Supply Air Duct Center Divider
1
261396
261397
261419
J
Return Air Duct Partition
1
261662
261663
261675
K
Vertical Divider (lower part) between
Supply and Return Air Ducts
1
261666
261677
