71M651x Software User’s Guide
cmd_load()
implements user dialog for data/code
download/upload
none none load.c
cmd_meter() processes "M" commands none none display.c
cmd_mpu_data_access() processes context for MPU DATA none none access.c
cmd_power_save() processes power save command none none cmd_misc.c
cmd_rtc() processes RTC commands none none cmd_misc.c
cmd_trim() processes trim commands none none cmd_misc.c
cmin()
returns minimum of unsigned char 'a'
and 'b'.
U08 a, U08 b U08 library.c
compare_falling_isr() discovers falling edges on port bits none none io651x.c
compare_int_enable()
enables interrupts from the analog
comparators
enum COMPARE comp_int none io651x.c
compare_rising_isr() discovers rising edges on port bits none none io651x.c
compare_status()
gets the status of the comparator
inputs
none U08 io651x.c
complement_x()
x = x0 ^ 1s; takes ones-complement of
n-byte 'x0'.
U08x *x, U08x *x0, n none classics.c
count_pulses()
adds the incremental pulse counts
taken by the DIO ISRs to the absolute
pulse counters (revision 3.05 only)
none none ce.c
CRC_Calc()
calculates standard 16-bit CRC poly-
nomial per ISO/IEC 3309 on flash
memory (x
16 +x 12 +x 5 +1)
U08r *ptr, U16 len, U01 set Bbool flash.c
CRC_Calc_NVR()
calculates the 16-bit CRC polynomial
per ISO/IEC 3309 on NVRAM
U08x *ptr, U16 len, U01 set Bbool library.c
ctoh()
converts ascii hex character to
hexadecimal digit
U08 c U08 load.c
divide() *u /= *v;
U08x *u, U08x *v, m, n,
U08x *v0
U08 classics.c
divide_ () *u /= *v;
U08x *u, U08x *v, m, n,
U08x *v0
none classics.c
divide_1() *x /= y; U08x *x, y, n none classics.c
done() exits control U08d *c *c cli.c
EEProm_Config()
connects/disconnects DIO4/5 for I2C
interface to serial EEPROM Bbool access, U16
page_size, U08 tWr
none eeprom.c
EEProm_Config()
connects/disconnects DIO4/5 for I2C
interface to serial EEPROM Bbool access, U16 pg_size,
U08 tWr
none eepromp.c
es0_isr () serial port 0 service routine none none serial.c
es1_isr() serial port 1 service routine none none serial.c
Events_Clear() clears the specified event U16 events none events.c
Events_Init() initializes events none none events.c
Ext_Int_Config()
configures the 8 external interrupts.
Selects trigger type and polarity. U08 Select, U08 Enable,
U08 EdgeRising
none misc.c
Ext_Int_Priority()
sets priority of all 7 external interrupts
to one of four values
U16 Select, U16 Priority none misc.c
Ext_Int_Read()
returns the value and enable status of
the 7 external interrupts U08x *pExtIntValue, U08x
*pExtInt
none misc.c
