71M651x Software User’s Guide

3.3.PROGRAMMING OF THE 71M651X CHIPS

There are two ways to download a hex file to the 71M651x Flash Memory:

Using a Signum Systems ADM-51 ICE.

Using the TERIDIAN Semiconductor Flash Download Board Module (FDBM).

The 71M651x also is available in a ROM version. Testing of the ROM version is supported with the onek_c.asm
assembler code.

For both programming and debugging code it is important that the hardware watchdog timer is
disabled. See the Demo Board User’s Manual for details.

3.4.TEST TOOLS

A command line interface operated via the serial interface of the 71M651X MPU provides a test tool that can be used
to exercise the functions provided by the low-level libraries. The command-line interface requires the following
environment:

1) Demo Code (651X_demo.hex) must be resident in flash memory

2) The Demo Board is connected via a Debug Board to a PC running Hyperterminal or another type of terminal

program.

3) The communication parameters are set at 9600 bps, 8N1, XON/XOFF flow control

3.4.1. Running the 651X_Demo.hex Program

This object file is the 71M651x embedded application developed by TERIDIAN to exercise all low-level function calls
using a serial interface. Demo Boards ship pre-installed with this program. To run this program:

Connect a serial cable between the serial port of the Debug Board RS232 and a COM port of a Windows
PC.

Open a Windows’ Hyperterminal session at 9600 bps, 8N1 with XON/XOFF flow control enabled.

Power on the Demo Board and hit a few times on the PC keyboard until ‘>’ is displayed on the
Hyperterminal screen.

Type ‘??’ for general usage help. Type ‘? [Cmd]’ for specific command help. For example, ?M will display
how to run the Meter Display command.

All references to ‘c’ (lower case c) indicate any ASCII character, all other lowercase letters are one-byte
numbers

Numbers can be entered in decimal by preceding them with a plus-sign (e.g. hex 20 = +32)

Revision 2.4

TERIDIAN Proprietary

18 of 137

© Copyright 2005-2006 TERIDIAN Semiconductor Corporation
