71M651x Software User’s Guide

RT

REAL TIME CLOCK
CONTROL

Description:

Allows user to read and set the real time clock.

Usage:

RT [option] [value] … [value]

Options:

Dy.m.d.w: Day of week

(year, month, day, weekday [1 = Sunday])

R

Read Real Time Clock.

Th.m.s

Time of day: (hr, min, sec).

As.t

Real Time Adjust: (speed, trim)

Example:

RTD05.03.17.5

Programs the RTC to Thursday, 3/17/2005

The “Military Time Format” is used for the RTC, i.e. 15:00 is 3:00 PM.

T

TRIM CONTROL

Description:

Allows user to read trim and fuse values.

Usage:

T [option]

Options:

4

Read fuse 4.

5

Read fuse 5.

6

Read fuse 6.

Example:

NONE

These commands are only accessible for the 6511H (0.1%) parts. When used on a 71M6511 (0.5%) part,
the results will be displayed as zero.

W

WATCHDOG RESET

Description:

Halts the Demo Code program, thus suppressing the triggering of the hardware
watchdog timer. This will cause a reset, if the watchdog timer is enabled.
Demo Code revision 3.05 only.

Usage:

W

Options:

NONE

Z

RESET

Description:

Soft Reset.

Usage:

Z

Options:

NONE

3.4.3. Command (Macro) Files

Commands or series of commands may be stored in text (ASCII) files and sent to the 71M651X using the “Transfer –
Send Text File” command of Hyperterminal or any other terminal program.
